Features:
Wattage:80W/100W/ 120W/150W/180W
Phillip/Osram/Samsung high quality SMD with excellent light performance
IP65 waterproof can resistant terrible weather
PF>0.9, Flicker free internal driver
Best choice for projects, 5 years warranty
General Information |
|
|
|
|
Light source type |
Phillip/Osram/Samsung |
|
Optical type |
SMD2835 |
Number of LED Chip |
N/A |
|
Control and dimming |
Non-dimmable |
Beam angle |
60°/90°/120° |
|
Driver Box |
N/A |
Color temperature |
3000K /4000K/5000K/6000K |
|
Protection class IEC |
Safety class II |
CRI |
70 |
|
Glow-wire test |
650°C, 30 s |
LED module replaceable |
NO |
|
UGR |
22 |
Number of LED driver |
1 unit |
|
SDCM |
< 5 |
Driver included |
Yes |
|
|
|
Driver replaceable |
No |
|
|
|
L90 lifetime of LED module |
50,000 hrs |
|
|
|
L80 lifetime of LED module |
100,000 hrs |
|
Dimension |
|
System Efficacy |
150 lm/W |
|
Diameter |
300mm |
Operating and Electrical |
|
|
Height |
125 mm |
Input Voltage |
220-240 Vac |
|
|
|
Input frequency |
50 to 60 Hz |
|
Mechanical and Housing |
|
System wattage |
80W/100W/120W/150W/180W |
|
Housing material |
Aluminum |
Rated output current |
pending on wattage |
|
Optical |
Reflector |
Rated output voltage |
24-42V DC |
|
Product color |
White/Black/Customize |
Power factor |
0.9 |
|
Heat sink material |
Die Cast Aluminum |
Flicker |
Flicker FREE |
|
Ingress protection code |
IP65 |
Certification |
ENEC,CCC,CB,CE |
|
Mech. impact protection code |
IK 08 |
IP Rating |
IP65 |
|
Package |
|
Surge protection |
2KV L-N |
|
QTY/CTN |
1pcs/CTN |
Ambient temperature range |
-30°C to + 50°C |
|
G.W/CTN |
2.1KG |
Performance ambient temperature Tq |
+25°C |
|
Carton size |
33.5x33x13CM |
